Remote Collaboration

Simple.  Rugged.  Secure.

Collaboration

DigiTech - The RealWear HMT-1Ultra-Low Bandwidth Solution

Introducing the digiTech Augmented Reality (AR) Solutions Kit, offered in both intrinsically safe (IS) and standard options. This rugged, hands-free, voice-based collaborative solution is easily deployable and purpose-built for ultra low-bandwidth, hard-to-reach environments.

Financing Now Available

100% hands-free design provides optimal safety and situational awareness in any environment.


Operates in ultra low bandwidth environments,

as low as 40Kbps,

with end-to-end encryption.

Ideal for remote technical support, inspections and equipment commissioning in the remotest of locations.

Virtually bring the subject matter expert or vendor aboard to assist with repairs or commissioning.

Training, support and inspections from platform to platform.

MINING

Secured connections in ultra low-bandwidth environments.

The Five Plus Telemedicine kit combines the benefits of five or more diagnostic tools specifically selected by medical professionals, and the digiMed® Consult dashboard for live streaming of encrypted device data — all integrated into one full featured kit. DigiGone's® innovative products facilitate immediate, round-the-clock phone and video medical consults for remote clients.

Learn More

A secure, hands-free, voice-based collaboration solution purpose built for ultra low bandwidth, hard to reach environments. Saving customers time and money by virtually bringing a subject matter expert to the source of the problem. This results in faster resolutions and enhanced operational efficiency.

Learn More

digiView® is a surveillance application that easily integrates with your existing CCTV system. Designed for use in maritime, oil and gas, mining and other locations, providing instant situational awareness of your remote assets.

Learn More

Encrypted video teleconferencing, keeping you in touch with your teams as they travel abroad.

Learn More
End-to-end encryption.
Consult expertise for repairs at remote sites.
Increased productivity.

RealWear HMT-1 integrated with digiTech® Capabilities

  • Encryption

    DigiTech uses the NIST approved Rjindael 256-bit AES algorithm on Packet Encryption for data sent to and from the Secured Proxy Servers. All Video, Audio, Texting and File Transfer capabilities are encrypted from end to end and all encryption and decryption takes place at each client end point. All traffic passes through the network in encrypted format. digiChat software encryption meets the HIPAA Security Rule along with the HITECH Act, part of the American Recovery and Reinvestment Act of 2009.


    The Advanced Encryption Standard (AES) specifies a Federal Information Processing Standards (FIPS)-approved cryptographic algorithm that can be used to protect electronic data. The AES algorithm is a symmetric block cipher that can encrypt (encipher) and decrypt (decipher) information. Encryption converts data to an unintelligible form called ciphertext; encrypting the ciphertext converts the data back into its original form, called plaintext. The AES algorithm is capable of using cryptographic keys of 128, 192, and 256 bits to encrypt and decrypt data in blocks of 128 bits.

  • 100% Handsfree

    The HMT-1 is completely handsfree and not tethered to another device like other headset or eye glass designs.  The voice based operating system with local speech recognition provides clarity even in noisy environments freeing up your hands to perform the tasks required.

  • Powerful Audio & Noise Cancellation

    The HMT-1 has integrated speakers and 3.5 mm audio cable jack for use with hearing protection.


    Four digital microphones and advanced algorithms – performs at 100dB

  • Video & Audio Teleconferencing

    Our integrated digiTech allows for peer-to-peer and peer-to-multi peer encrypted Video and Audio conferencing via a “Meet Me/Chat Room” type connection concept.


    Each guest has the ability to observe or participate in the video conference, by a single voice command to listen and observe. Using a seperate voice command, they can toggle their camera on/off their camera as well as their microphone to participate.


    There is virtually no limit to the number of Guests who may participate in a video conference. However, the speed of the device processors and the capacity of the Communications Servers on which the conference is running may impact the actual number of parties who can participate or be observed at the same time.

  • File Transfer

    digiTech allows for files to be transferred or received in encrypted format to any or all of the participants on a video or audio teleconference or streaming session.  Using a few simple voice commands, the wearer selects or deselects which conference participants will receive the file, selects the file to transfer then uploads the file to the recipients. The file sender is informed, in the IM Texting window, of which participants to whom the file is being uploaded, when each file is uploaded, and confirmation that the file was either received or rejected by each intended recipient. Simple, in realtime and secure.

  • IM Chat

    Using your voice, you can IM Chat with those on the secure channel when bandwidth is so low or unreliable it won't support audio.

  • Private, Secure Network

    As an option, you can install DigiGone's encrypted communication server software application on your own secure network to ensure your communications stay within your corporate network. You won't need to worry about your communications being 'routed' through other servers.

  • Longevity

    The HMT-1 with digiTech will operate for up to five or more continuous hours before requiring a recharge or battery 'hot swap'.

  • Rugged and Durable Design

    The RealWear HMT-1-


    PPE Compatible: Designed to work with standard hard helmets, bump caps and safety glasses.


    Full Shift Internal Battery: Field swappable for continuous use.


    Outdoor Display:  Viewable in bright sunlight.


    Water Resistant (IP66): Protected against heavy seas or powerful jets of water.


    Dust Tight (IP66): Complete protection against the ingress of micro particles.


    Shock Resistant: Durable for up to a 2 meter drop onto concrete from any angle.


    Rugged Build: Fully operational from -20 to 50 degrees Celsius.


  • HMT-1 Technical Specs

    Core Platform & Functions


    Operating System

    Android 8.1.0 (AOSP) + WearHF™ hands-free interface


    Chipset

    2.0 GHz 8-core Qualcomm® Snapdragon™ 625 with Adreno 506 GPU – OpenGL ES 3.1 & OpenCL 2.0


    Memory

    16 GB Internal Storage / 2 GB RAM / MicroSD slot (max card supported 256 GB)


    Included Applications

    Document Navigator, Camera with Barcode Reader, Video Recorder, Media Player


    Languages Supported

    English, Spanish, French, German, Italian, Portuguese, Russian, Mandarin Chinese, Japanese, Korean, Thai, Polish


    Connectivity & Sensors

    Bluetooth

    Bluetooth Low Energy 4.1

    Operating Frequency Bands for RealWear HMT-1

    Wi-Fi operating frequency band(s) details are as follows:

    • 802.11a: 14.34dBm

    • 802.11b: 13.32dBm

    • 802.11g: 12.29dBm

    • 802.11n HT20: 11.25dBm

    • 802.11n HT40: 11.39dBm

    • 802.11ac: 12.26dBm


    5G Wi-Fi Connection Information

    Operations in the 5.15 — 5.35GHz band are restricted to indoor use only.


    Bluetooth

    Bluetooth Low Energy 4.1: 10.55 dBm


    Wi-Fi

    802.11 a/b/g/n/ac – 2.4GHz and 5GHz


    GPS and Location

    GPS, GLONASS, A-GPS


    IMU

    9-DOF (3-axis accelerometer, magnetometer, and gyroscope), software enhanced stabilization


    Accessories

    Carrying case

    Swappable battery

    Plug in earpiece



    Resources Required

     Internet Connectivity- WiFi hotspot

     Power- Internal how swappable battery


    Special Certifications

     We have an Intrinsically Safe version (HMT-1Z1)

digiTech® User Interface

  • Bandwidth Select™

    Using a few simple verbal commands, you  control the amount of bandwidth used by the digiTech application and you can do this in real time.  This is accomplished by “gating” the bandwidth usage at your selected maximum of as little as 40Kbps for full use of all encrypted video, audio, IM chat and file transfer capabilities. Bandwidth Select™ is a “gate” in that you select the maximum bandwidth (from 40 Kbps to 500 Kbps) digiTech will use. However, the application only uses what it actually needs, up to the maximum set. Bandwidth Select™ also allows you to independently set the maximum “gate” for Audio bandwidth use at either no more than 8 Kbps or no more than 12 Kbps.

  • Frames-per-Second (FPS) Selection

    Using only your voice, you can adjust the Frames-per-Second on the fly. The FPS rate may be adjusted from 5 to 15 FPS. While FPS selection effects the fluid motion of the video experience, it also allows for Bandwidth Usage Reduction and Savings due to the fact that fewer frame updates require less bandwidth and digiChat’s Bandwidth Select™ feature is programmed to use only as much bandwidth is required, up to the user selected maximum.

  • “Video/Audio Only” Viewing

    One voice command turns off your camera and/or microphone during a video or audio teleconference so you can only view and/or listen to the conference. In this mode, you only transmit at less than 1 Kbps and receive as little as 6-8 Kbps for an “audio only” conference and as little as 30-40Kbps for a video conference. Critical in austere environments where bandwidth is restricted.
